Chinese Lithium Cells Manufacturer Custom-made Battery For Table Lamp UFX 402065 550mAh 3.7V Lipo Battery With KC Certification

$1.40
In stock
SKU
UFX 402065

FOB Price: US $1.2 - 1.5 / Ampere
Min.Order Quantity: 1000 Ampere/
Please contact us for the order !

  •     Place of Origin: Guangdong, China
        Brand Name: UFX
        Model Number: 402065
        Type: Li-polymer
        Nominal Voltage: 3.7V
        Size: 4*20*67mm
        Nominal Capacity: 550mAh
        Product name: UFX 402065 Li-ion Battery
        Warranty: 1 Year
        Weight: 10g
        Cycle life: 500 Times
        Application:  Table Lamp Product
        Certificate: KC
        Payment: Paypal.TT.Escrow.Western Union
        Max charge current: 1C



Table Lamp Battery UFX 402065 550mAh 3.7V Lipo Battery With KC Certification

402065 550mAh 3.7V Lipo Battery



550mAh Battery for Table Lamp

550mAh with KC Certification

550mAh with KC Certification

 Battery for Table Lamp

Product Parameters

No.

Item

General Parameter

Remark

1

Rated Capacity

Typical

580mAh

Standard discharge(0.2C C5A) after Standard charge

Minimum

550mAh

2

Nominal Voltage

3.7V

Mean Operation Voltage

3

Voltage at end of

3.0V

Discharge Cut-off Voltage

Discharge

4

Charging Voltage

4.2±0.03V



5

Internal Impedance

≤175mΩ

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after shipment and cycles no more than 5 times

6

Standard charge

Constant Current 0.2C5A

Charge time : Approx 6h

Constant Voltage 4.2V

0.01 C5A cut-off

7

Standard discharge

Constant current 0.2 C5A



end voltage 3.0V

8

Fast charge

Constant Current 0.5C5A

Charge time : Approx 2.5h

Constant Voltage 4.2V

0.01 C5A cut-off

9

Fast discharge

Constant current 0.5C5A



end voltage 3.0V



10

Maximum Continuous Charge Current

1 C5A



11

Maximum Continuous Discharge Current

1C5A



12

Operation Temperature Range

Charge: 0~45

60±25%R.H.

Bare Cell

Discharge: -20~60



13

Storage Temperature Range

Less than 1 year: -20~25

60±25%R.H.

less than 3 months: -20~40℃

at the shipment state

14

Pack  Dimension

High: max67mm

Width: max20mm
Thickness: max4mm

Initial  Dimension



Discharge Rate Characteristicsli-ion battery
